particles.hpp File Reference

#include <Cabana_AoSoA.hpp>
#include <Kokkos_Core.hpp>
#include "globals.hpp"
#include "particles.tpp"

Include dependency graph for particles.hpp:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	SimdPhase
struct	SimdConstants
struct	SimdParticles
struct	VecPhase
struct	VecConstants
struct	VecParticles
struct	VecParticlesSimple< T >
struct	OneParticle< T >
struct	AoSoAIndices< Device >

Typedefs
using	ParticleDataTypes = Cabana::MemberTypes< double[6], double[3], long long int >
using	PhaseDataTypes = Cabana::MemberTypes< double[6]>

Functions
KOKKOS_INLINE_FUNCTION void	update_phases (SimdPhase &ph_new, const SimdPhase &ph, double local_dt, const SimdPhase &dph)
KOKKOS_INLINE_FUNCTION void	simd_2_AoSoA (VecParticles *part, const SimdParticles &part_one, int a_vec, int s_vec)
KOKKOS_INLINE_FUNCTION void	AoSoA_2_simd (SimdParticles &part_one, const VecParticles *part, int a_vec, int s_vec)
KOKKOS_INLINE_FUNCTION void	update_dphm (SimdPhase &dphm, const SimdPhase &dpht)
KOKKOS_INLINE_FUNCTION void	update_dpht (SimdPhase &dpht, const SimdPhase &dph, const SimdPhase &dphm)
template<class Device >
int	p_range (int num_particle)
template<>
int	p_range< DeviceType > (int num_particle)
int	add_vec_buffer (int n_ptl)

Typedef Documentation

using ParticleDataTypes = Cabana::MemberTypes<double[6],double[3],long long int>

using PhaseDataTypes = Cabana::MemberTypes<double[6]>

Function Documentation

int add_vec_buffer ( int  n_ptl )

inline

Return n_ptl rounded up to the nearest full vector

Here is the call graph for this function:

Here is the caller graph for this function:

KOKKOS_INLINE_FUNCTION void AoSoA_2_simd	(	SimdParticles &	part_one,
		const VecParticles *	part,
		int	a_vec,
		int	s_vec
	)

Copy from the AoSoA to a local SoA of array length SIMD_SIZE. This should be obsolete at some point

Parameters

[out]	part_one	The local SimdParticle array
[in]	part	The particle AoSoA
[in]	a_vec	The index in the inner array of the AoSoA
[in]	s_vec	The index in the outer array of the AoSoA

Here is the caller graph for this function:

template<class Device >

int p_range ( int  num_particle )

inline

Determine parallel for range for particles. Returns number of vectors

Parameters

[in]

num_particle

Number of particles

Here is the call graph for this function:

template<>

int p_range< DeviceType > ( int  num_particle )

inline

Determine parallel for range for particles. Returns number of particles

Parameters

[in]

num_particle

Number of particles

Here is the caller graph for this function:

KOKKOS_INLINE_FUNCTION void simd_2_AoSoA	(	VecParticles *	part,
		const SimdParticles &	part_one,
		int	a_vec,
		int	s_vec
	)

Copy from local SoA of array length SIMD_SIZE back into the AoSoA. This should be obsolete at some point

Parameters

[in,out]	part	The particle AoSoA
[in]	part_one	The local SimdParticle array
[in]	a_vec	The index in the inner array of the AoSoA
[in]	s_vec	The index in the outer array of the AoSoA

Here is the caller graph for this function:

KOKKOS_INLINE_FUNCTION void update_dphm	(	SimdPhase &	dphm,
		const SimdPhase &	dpht
	)

Add the second vector of phase derivatives to the first (for use in RK4)

Parameters

[in,out]	dphm	Vector of phase derivatives
[in]	dpht	Vector of phase derivatives

Here is the caller graph for this function:

KOKKOS_INLINE_FUNCTION void update_dpht	(	SimdPhase &	dpht,
		const SimdPhase &	dph,
		const SimdPhase &	dphm
	)

Add the second vector of phase derivatives and 2x the third vector to the first, i.e. dpht = dpht + dph + 2 dphm (for use in RK4)

Parameters

[in,out]	dpht	Vector of phase derivatives
[in]	dph	Vector of phase derivatives
[in]	dphm	Vector of phase derivatives

Here is the caller graph for this function:

KOKKOS_INLINE_FUNCTION void update_phases	(	SimdPhase &	ph_new,
		const SimdPhase &	ph,
		double	local_dt,
		const SimdPhase &	dph
	)

Update a vector of particle phases with a time step

Parameters

[out]	ph_new	Vector of new phase
[in]	ph	Vector of old phase
[in]	local_dt	Time step size
[in]	dph	Vector of time derivatives of the phase

Here is the caller graph for this function:
