Functions/Subroutines
real(8) function	exp_ad (x)
	adjusted exponential function for adiabatic response More...

subroutine	set_f0_f0g_ptr (f0_inode1_new, f0_inode2_new, f0_f0g_cpp)

subroutine	f0_init_decomposed_ptrs (f0_T_ev_cpp, f0_fg_T_ev_cpp, f0_inv_grid_vol_cpp, f0_grid_vol_cpp, f0_grid_vol_vonly_cpp, f0_den_cpp, f0_flow_cpp)

subroutine	f0_get_f0g (grid, isp, itr, p, phi, mu_n_in, vp_n, f0g, err)
	Interpolates the grid distribution function to real space, velocity space location given by node, mu_n,vp_n. In poloidal plane it uses nearest neighbor and velocity space linear interpolation. More...

subroutine	f0_set_ptrs (nnode, f0_delta_n_cpp, f0_delta_u_cpp, f0_delta_T_cpp)
	Sets pointers to cpp arrays for f0 arrays. More...

real(8) function	f0_mu_vol_fac (ivr)
	Returns the v_perp/mu boundary factor for velocity integration Boundary vertices have only half the volume of an interior vertex. More...

real(8) function	f0_vp_vol_fac (ivz)
	Returns the v_parallel boundary factor for velocity integration Boundary vertices have only half the volume of an interior vertex. More...

Variables
integer	f0_nmu

integer	f0_nvp

real(8), dimension(:,:,:,:), pointer	f0_f0g => NULL()
	Stores the slow varying grid part of the distribution function. More...

real(8)	f0_smu_max

real(8)	f0_vp_max

real(8)	f0_dsmu

real(8)	f0_dvp

real(8), dimension(:,:), pointer	f0_inv_grid_vol

real(8), dimension(:,:), pointer	f0_grid_vol

real(8), dimension(:,:), pointer	f0_grid_vol_vonly

real(8), dimension(:,:), pointer	f0_den

real(8), dimension(:,:), pointer	f0_t_ev

real(8), dimension(:,:), pointer	f0_flow

real(8), dimension(:,:), pointer	f0_fg_t_ev

real(8), dimension(:,:), pointer	f0_delta_n
	Flux-surface averaged change of density. More...

real(8), dimension(:,:), pointer	f0_delta_u
	Flux-surface averaged change of parallel flow. More...

real(8), dimension(:,:), pointer	f0_delta_t
	Flux-surface averaged change of temperature. More...

real(kind=8), parameter	f0_mu0_factor =3D0
	Set value of lowest mu in grid --> 1/f0_mu0_factor. More...

logical	f0_use_linear_adiabatic = .false.

real(8), parameter	f0_linear_adiabatic_bd =0.7

Function/Subroutine Documentation

◆ exp_ad()

real (8) function f0_module::exp_ad ( real (8), intent(in) x )

adjusted exponential function for adiabatic response

Here is the caller graph for this function:

◆ f0_get_f0g()

subroutine f0_module::f0_get_f0g	(	type(grid_type)	grid,
		integer, intent(in)	isp,
		integer, intent(in)	itr,
		real (8), dimension(3), intent(in)	p,
		real (8), intent(in)	phi,
		real (8), intent(in)	mu_n_in,
		real (8), intent(in)	vp_n,
		real (8), intent(out)	f0g,
		logical, intent(out)	err
	)

Interpolates the grid distribution function to real space, velocity space location given by node, mu_n,vp_n. In poloidal plane it uses nearest neighbor and velocity space linear interpolation.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ f0_init_decomposed_ptrs()

subroutine f0_module::f0_init_decomposed_ptrs	(	real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_T_ev_cpp,
		real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_fg_T_ev_cpp,
		real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_inv_grid_vol_cpp,
		real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_grid_vol_cpp,
		real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_grid_vol_vonly_cpp,
		real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_den_cpp,
		real(8), dimension(f0_inode1:f0_inode2, ptl_isp:ptl_nsp), target	f0_flow_cpp
	)

◆ f0_mu_vol_fac()

real (8) function f0_module::f0_mu_vol_fac ( integer, intent(in) ivr )

Returns the v_perp/mu boundary factor for velocity integration Boundary vertices have only half the volume of an interior vertex.

Parameters

[in] ivr v_perp velocity grid index (0...f0_nmu)

Returns: f0_mu_vol_fac 0.5 if input vertex is on the v_perp boundary, 1.0 otherwise

Here is the caller graph for this function:

◆ f0_set_ptrs()

subroutine f0_module::f0_set_ptrs	(	integer, intent(in), value	nnode,
		real(8), dimension(nnode, 0:ptl_nsp), target	f0_delta_n_cpp,
		real(8), dimension(nnode, 0:ptl_nsp), target	f0_delta_u_cpp,
		real(8), dimension(nnode, 0:ptl_nsp), target	f0_delta_T_cpp
	)

Sets pointers to cpp arrays for f0 arrays.

Parameters

[in] nnode Number of mesh vertices, integer

◆ f0_vp_vol_fac()

real (8) function f0_module::f0_vp_vol_fac ( integer, intent(in) ivz )

Returns the v_parallel boundary factor for velocity integration Boundary vertices have only half the volume of an interior vertex.

Parameters

[in] ivz v_para velocity grid index (0...2*f0_nvp)

Returns: f0_vp_vol_fac 0.5 if input vertex is on the v_parallel boundary, 1.0 otherwise

Here is the caller graph for this function:

◆ set_f0_f0g_ptr()

subroutine f0_module::set_f0_f0g_ptr	(	integer, intent(in), value	f0_inode1_new,
		integer, intent(in), value	f0_inode2_new,
		real(8), dimension(-f0_nvp:f0_nvp, f0_inode1_new:f0_inode2_new, 0:f0_nmu, ptl_isp:ptl_nsp), target	f0_f0g_cpp
	)

Variable Documentation

◆ f0_delta_n

real (8), dimension(:,:), pointer f0_module::f0_delta_n

Flux-surface averaged change of density.

◆ f0_delta_t

real (8), dimension(:,:), pointer f0_module::f0_delta_t

Flux-surface averaged change of temperature.

◆ f0_delta_u

real (8), dimension(:,:), pointer f0_module::f0_delta_u

Flux-surface averaged change of parallel flow.

◆ f0_den

real (8), dimension(:,:), pointer f0_module::f0_den

◆ f0_dsmu

real (8) f0_module::f0_dsmu

◆ f0_dvp

real (8) f0_module::f0_dvp

◆ f0_f0g

real (8), dimension(:,:,:,:), pointer f0_module::f0_f0g => NULL()

Stores the slow varying grid part of the distribution function.

◆ f0_fg_t_ev

real (8), dimension(:,:), pointer f0_module::f0_fg_t_ev

◆ f0_flow

real (8), dimension(:,:), pointer f0_module::f0_flow

◆ f0_grid_vol

real (8), dimension(:,:), pointer f0_module::f0_grid_vol

◆ f0_grid_vol_vonly

real (8), dimension(:,:), pointer f0_module::f0_grid_vol_vonly

◆ f0_inv_grid_vol

real (8), dimension(:,:), pointer f0_module::f0_inv_grid_vol

◆ f0_linear_adiabatic_bd

real (8), parameter f0_module::f0_linear_adiabatic_bd =0.7

◆ f0_mu0_factor

real (kind=8), parameter f0_module::f0_mu0_factor =3D0

Set value of lowest mu in grid --> 1/f0_mu0_factor.

◆ f0_nmu

integer f0_module::f0_nmu

◆ f0_nvp

integer f0_module::f0_nvp

◆ f0_smu_max

real (8) f0_module::f0_smu_max

◆ f0_t_ev

real (8), dimension(:,:), pointer f0_module::f0_t_ev

◆ f0_use_linear_adiabatic

logical f0_module::f0_use_linear_adiabatic = .false.

◆ f0_vp_max

real (8) f0_module::f0_vp_max
